MIL-DTL-83526C
1.3 Part or Identifying Number (PIN). The PIN is in the following format, consisting of the letter "M"
followed by the basic specification number, sequentially assigned dash number and additional
M 83526/
XX - X
X
X
X
Denotes military specification
Basic specification number
Specification sheet number
Number of terminus positions required
Quantity
Designator
2
A
4
B
6
C
8
D
10
E
12
F
Cable size 1/
Designator
Cable Jacket OD in Inches
0.178
-
0.216
1
0.217
-
0.256
2
Terminus supplied for actual fiber size 2/
Fiber OD in microns
Designator
123.0 - 124.4
A
124.5 - 127.0
B
138.0 - 139.6
C
139.7 - 142.0
D
No termini specified
E
Keying position for terminus insert arrangement
Position
Designator
A (STD)
1
B (non rated 60°)
2
No altering keying
Position required
3
1/ Select cable size and type in accordance with MIL-PRF-85045.
2/ Select fiber size and tolerance in accordance with MIL-PRF-49291.
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3, 4 or 5 of this
specification. This section does not include documents cited in other sections of this specification or
recommended for additional information or as examples. While every effort has been made to ensure the
completeness of this list, document users are cautioned that they must meet all specified requirements of
documents cited in sections 3, 4 or 5 of this specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and
handbooks form a part of this document to the extent specified herein. Unless otherwise specified, the
issues of these documents are those cited in the solicitation or contract (see 6.2).
