MIL-PRF-29504/4D
TABLE I TICC numbers and "A" (ferrule hole) diameter
for specified optical fiber sizes.
Fiber size
Ferrule hole
Ferrule
Circular
TICC
TICC
TICC
(core/cladding)
diameter
material
run-out
style 1
style 2
style
µm
µm
µm
3
Single mode < 9/125 1/
125 +1/-0
Ceramic
1 2/
4300
4303
4306
Single mode < 9/125 1/
125.5 +1/-0
Ceramic
1 2/
4301
4304
4307
Single mode < 9/125 1/
126 +1/-0
Ceramic
1 2/
4302
4305
4308
Single mode 9/125 1/
125 +1/-0
Ceramic
1 2/
4207
4217
4265
Single mode 9/125 1/
125.5 +1/-0
Ceramic
1 2/
4208
4218
4266
Single mode 9/125 1/
126 +1/-0
Ceramic
1 2/
4209
4219
4267
50/125, 62.5/125
126 +2/-0
Ceramic
2
4210
4220
4268
50/125, 62.5/125
127 +2/-0
Ceramic
2
4040
4221
4269
62.5/125/153
156 +3/-0
Ceramic
3
4211
4222
4270
62.5/125/155
157 +3/-0
Ceramic
3
4212
4223
4271
100/140
142 +3/-0
Ceramic
4
4043
4224
4272
100/140
145 +3/-0
Ceramic
4
4044
4225
4273
100/140/172
173 +1/-0
Ceramic
2
4293
4294
4295
100/140/172
173 +3/-0
Ceramic
4
4087
4226
4274
100/140/172
175 +3/-0
Ceramic
4
4213
4227
4275
200/230
236 +4/-0
Ceramic
8
4214
4228
4276
200/280
286 +4/-0
Ceramic
8
4215
4229
4277
400/440
448 +4/-0
Ceramic
8
4216
4230
4278
50/125, 62.5/125
127 +3/-0
Metal 3/
3
4231
62.5/125/155
157 +3/-0
Metal 3/
3
4232
100/140
142 +3/-0
Metal 3/
4
4233
100/140/172
175 +3/-0
Metal 3/
4
4234
200/230
236 +4/-0
Metal 3/
8
4235
1/
Applicable to any single mode core size. Also applicable to any multimode core size when
enhanced performance is required and cladding tolerances permit.
2/ Circular run-out of 0.5 microns preferred, as it becomes more standard in industry.
3/ Termini with metal ferrules are intended primarily for legacy systems.
4
