MIL-PRF-29504/4D
Part or identifying number (PIN): See table II and 6.6 of MIL-PRF-29504.
M
29504
/
4
-XXXX
Prefix
Basic
specification
Specification
sheet
TICC code
(see table I)
Usage: Termini compliant with this specification sheet are intended to be used in MIL-DTL-38999
connectors as applicable, may be used in connectors other than MIL-DTL-38999 at the discretion of the
acquiring activity. Termini compliant with this specification may not meet all requirements of MIL-DTL-
38999 if not used in a series III connectors. Termini with metal ferrules are intended primarily for legacy
systems.
REQUIREMENTS:
Temperature ranges:
(-55°C to +165oC)
Operating:
-67°F to 329°F
(-40°C to + 85oC)
Non-operating:
-40°F to 185°F
(-40°C to +85oC)
Storage:
-40°F to 185°F
Fabrication procedure. Standard fabrication procedure (for terminus placement/termination onto the
end of an optical fiber), including epoxy specified in the procedure, shall be used for test sample
terminations. Test sample configurations and fabrication shall be performed as specified in NAVSEA
Drawing 8283255. A copy of this document can be obtained at web site:
https://fiberoptics.nswc.navy.mil/ in the NAVSEA Drawing section under Component Information.
Design and construction:
Dimensions and configuration: See figure 1 and table I. Pre-polished termini may have either flat or
radiused end faces. Regardless of the end face geometry, the terminus shall meet the requirements
of this specification when terminated using the procedures specified.
Weight: 1.0 gram maximum.
3
