MIL-PRF-24623C
TABLE III.
Group A inspection.
Inspection
Application
Requirement
Test method
paragraph
paragraph
Cable
Fiber
splice
splice
Visual and mechanical
Size 1/
X
X
3.5.1
4.7.2.1
Identification marking 1/
X
X
3.5.4
4.7.2.4
Workmanship
X
X
3.8
4.8
1/
In process controls may be used by the manufacturer in lieu of this
group A test.
4.6.1.3 Group B inspection. Group B inspection shall consist of the optical test
specified in table IV and shall be performed on sample units which have been subjected
to and have passed the group A inspection. The maximum time from the end of one group
B inspection to the beginning of the following group B inspection shall be not greater
than 24 months.
TABLE IV.
Group B inspection.
Inspection
Requirement paragraph
Test method paragraph
Insertion loss
3.6.1
4.7.3.1
4.6.1.3.1 Disposition of samples.
Samples subjected to group B inspection shall not
be shipped.
4.6.1.3.2 Sampling plan. Six specimens shall be selected from a lot of the same PIN
within 24 months after the date of notification of qualification and during every 24
month period thereafter, except when the total production in a 24 month period is less
than 250 units of product or a total of 60 months have elapsed since the inspection
was performed, in which case only three specimens shall be tested.
4.6.1.3.3 Failures. If one or more sample units fail to pass group B inspection, the
lot from which the samples were selected shall be rejected.
4.6.1.3.4 Rejected lots.
Requirements regarding the rework of rejected lots shall
be as identified in the qualification instructions (see 6.7.1).
4.6.2 Periodic inspection (group C). Inspection of product for qualification
verification shall consist of group C inspections, as specified in table V. The
inspections shall be run in the order shown on sample units which have passed groups A
and B inspections. Except where the results of the inspections show noncompliance
with the applicable requirements (see 4.6.2.4), delivery of inspection lots which have
passed group B inspection shall not be delayed pending the results of group C
inspection. Group C inspection shall be performed every 60 months following
notification of qualification acceptance.
4.6.2.1 Disposition of sample units. Sample units which have been subjected to
group C inspection shall not be shipped.
4.6.2.2 Sampling plan. Every 60 months, eight sample units of the same PIN, which
have passed group B inspection, shall be selected.
4.6.2.3 Failures. One or more specimen or sample units failures shall constitute
group C inspection failure.
4.6.2.4 Noncompliance. Requirements regarding failure of group C inspection shall
be as identified in the qualification instructions (see 6.7.2).
11
