MIL-PRF-29504/5D
21. For style 1 and 3 terminus only, reduction of the .225 inch (5.72 mm) minimum length to .025 inch
(0.63 mm) is allowed. Additionally there shall be a smooth ramp transition on the terminus
between the terminus barrel and the crimp sleeve/heat shrink so as not to restrict the function of
the insertion and removal tool during the removal operation.
22. Terminus compression spring shall withstand an applied force of 8 pounds minimum with no
damage.
FIGURE 1. Socket terminus - Continued.
Part or identifying number (PIN): See table II of this document and 6.6 of MIL-PRF-29504.
M
29504
/
5
-XXXX
Prefix
Basic
specification
Specification
sheet
TICC code
(see table I)
Usage: Termini compliant with this specification sheet are intended to be used in MIL-DTL-38999
connectors as applicable, and may be used in connectors other than MIL-DTL-38999 at the discretion of
the acquiring activity. Termini compliant with this specification may not meet all requirements of MIL-DTL-
38999 if not used in a series III connectors.
REQUIREMENTS:
Temperature ranges:
-67°F to 329°F (-55°C to +165oC)
Operating:
-40°F to 185°F (- 40°C to + 85oC)
Non-operating:
-40°F to 185°F (-40°C to +85oC)
Storage:
Fabrication procedure. Standard fabrication procedure (for terminus placement/termination onto the
end of an optical fiber), including epoxy specified in the procedure, shall be used for test sample
terminations. Test sample configurations and fabrication shall be performed as specified in NAVSEA
Drawing 8283255. A copy of this document can be obtained at Web Site:
https://fiberoptics.nswc.navy.mil/ in the NAVSEA Drawing section under Component Information.
Design and construction:
Dimensions and configuration: See figure 1 and table I. Pre-polished termini may have either flat or
radiused end faces. Regardless of the end face geometry, the terminus shall meet the requirements of
this specification when terminated using the procedures specified.
Weight: 1.0 gram maximum.
