MIL-PRF-29504/13A
Test specimens: Test specimens shall be constructed using a 62.5/125 micron
optical fiber within a single fiber cable with an outer diameter not greater
than 2.4 mm.
Part or identifying number (PIN):
See table I and 6.6 of MIL-PRF-29504.
M29504/13
XXXX
X
|
|
|
Basic specification
TICC Code
Crimp sleeve
and specification
(see table I) (optional)
sheet
Usage: Termini compliant with this specification sheet may be used in
connectors other than MIL-PRF-28876 at the discretion of the acquiring
activity.
TABLE 1.
TICC numbers to fiber diameter cross reference.
TICC number
A diameter (hole diameter) 1/
µm 2/
Multimode
Single-mode
Inches
+0.0001
+2.5
-0.0000
-0.0
4107
4117
0.0048
122.0
4108
4118
0.0049
124.5
4109
4119
0.0050
127.0
4110
4120
0.0051
129.5
4111
4121
0.0054
137.0
4112
4122
0.0055
139.5
4113
4123
0.0056
142.0
4114
4124
0.0057
145.0
4115
4125
0.0091
231.5
4116
4126
0.0092
234.0
1/ For maximum performance, termini should be selected for the best
(tightest) fit to the fiber. Fitting the next size larger terminus
to a fiber may affect connector performance.
2/ Rounded to the nearest 0.5 µm.
