MIL-DTL-83522/16C
TABLE I. MIL-DTL-83522/16-ANX, -ANY, -DNX & -DNY ST connector MIL-DTL-83522/17-NX & -NY ST-TO-ST adapter:
Initial qualification, requalification: change in design/material Continued.
Optical
Initial
Requalification for M83522/16 & /17
test
qualification
done as
for
Initial
Change
ANX, ANY
Change in
part of test
M83522
qualification
in boot
change in
metallic
performed
/16 & /17
5/
Test performed
ANX &
material
boot insert
material
ANY after
design
DNX &
DNY
qualification
11/,
Group 5
Thermal vacuum outgassing
Residual magnetism
Odor
Toxicity
Notes:
1. OOT = Change in optical transmittance
-a = measurement after test
-d = measurement during & after test
2. OIL = Insertion loss.
3. ORL = Return loss.
4. MSG = Signal discontinuity.
5/ Change in material for this note relates to a change in the metallic material for the ST connector bayonet cap,
barrel, and (if metal) boot insert and for the ST-to-ST adapter housing.
6/ If there is a change in material.
7/ If the material change is a non-metal one.
8/ Perform a subset of dimensional inspection. Subset = subset of dimensional inspections that pertain to part
(such as barrel, bayonet cap or boot) being changed.
9/ Either an additional four mated pair can be fabricated for this test or the Group 3 samples may be used after
completion of Group 3 tests.
10/ Polymeric parts from 1 mated pair.
11/ Two mated pair from Group 2.
12/ When performing initial qualification or re-qualification for both single mode (SM) and for multimode (MM), four
MM Mated pairs must undergo Group 1 and shock testing only. Ten single mode mated pair undergo specified
inspections/tests. This multimode qualification by similarity is applicable if only differences, between SM and
MM, are ferrule diameter dimension, ferrule hole diameter dimension, boot color (optional) and markings.
13/ Group 1 mated pair are to be used for Groups 2, 3 and 4.
Referenced documents. In addition to MIL-DTL-83522, this specification sheet references the following
documents:
MIL-DTL-83522/17
MIL-PRF-85045
SAE AMS-QQ-S-763
ASTM A-276
ASTM B-16/B16M
Changes from previous issue. Marginal notations are not used in this revision to identify changes with respect to
the previous issue due to the extent of the changes.
8
