MIL-PRF-28876/6E
Termini: Style P (pin) or S (socket). See MIL-PRF-29504/1, MIL-PRF-
29504/2, MIL-PRF-29504/12, MIL-PRF-29504/13, MIL-PRF-29504/14, and MIL-PRF-
29504/15 (For dummy terminus, see MIL-PRF-29504/3).
Insert retention nut:
Unless otherwise specified in the PIN, supplied with
the connector.
Cleaning procedures: Each shipment of connectors shall include recommended
cleaning procedures. The following wording or equivalent is recommended:
"To clean, use lint free wipe dampened with alcohol and blow dry with air".
Shell polarization: 1 through 6 keyway positions.
See MIL-PRF-28876
appendix A, figure A-3.
Marking:
PIN:
Marked on coupling nut of plug (see table I).
M28876/6
A
1
P
1
N
Basic PIN
Insert retention nut
not supplied
Shell size designator
Keying position number
Insert arrangement number
Terminus/insert style
TABLE I.
PIN designators.
Shell
Shell size
Insert
Termini
Key
size
designator
arrangement
position
number
11
A
1
P or S
1, 2, 3,
4, 5, or 6
13
B
1
P or S
1, 2, 3,
4, 5, or 6
15
C
1 or 2
P or S
1, 2, 3,
4, 5, or 6
23
F
1 or 2
P or S
1, 2, 3,
4, 5, or 6
Mating counterpart: Receptacle connectors specified in MIL-PRF-28876/1
through MIL-PRF-28876/5 and MIL-PRF-28876/11 through MIL-PRF-28876/14.
Installation and removal tools:
As specified in NAVSEA drawing 6872813.
For qualified products listing, quality conformance, and periodic
inspections, dummy termini shall be used in all unused cavities.
3
