MIL-PRF-28876/6E
Color
Shell
N
O
Insert
band
size
dia
dia
figure
EIA-359
max
max
5/
11
.960
B-1
Yellow
1.028
(24.38)
(26.11)
B-2
Yellow
1.141
13
1.085
(28.98)
(27.56)
15
1.255
1.263
B-3
Yellow
(31.88)
(32.08)
or
B-4
1.705
23
1.695
B-5
Yellow
(43.05)
(43.31)
or
B-6
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Dimensions apply to plated/finished part.
4. Metric equivalents (mm) are in parentheses.
5. For insert arrangement, see the indicated figure in appendix B
of MIL-PRF-28876.
6. Connector insert retention nut internal configuration not shown.
The insert retention nut shall be in accordance with figure A-8
of MIL-PRF-28876.
Plug connector - Continued.
FIGURE 1.
REQUIREMENTS:
Dimensions and configurations: See figure 1 herein and MIL-PRF-28876
appendix A, figure A-1, and figure A-6.
Weight (without termini):
Weight (ounces, (gram)), maximum
Shell size
11
2.0
ounces
(56.7g)
13
2.5
ounces
(70.875 g)
15
3.0
ounces
(85.05 g)
23
4.3
ounces
(121.905 g)
Fiber optic cable:
Cable diameter:
.094 inch (2.4 mm) maximum.
Protective caps: Each connector shall be supplied with protective caps over
the front and rear portions of the connector.
Insert arrangement:
See appendix B of MIL-PRF-28876 for desired shell size.
2
