MIL-PRF-28876/14E
Cleaning procedures: Each shipment of connectors shall include recommended
cleaning procedures. The following wording or equivalent is recommended
"To clean, use lint free wipe dampened with alcohol and blow dry with air".
Sealing gasket and o-ring: The receptacle shall include a sealing gasket or
o-ring to seal between the receptacle flange and the mounting panel.
Shell polarization: 1 through 6 keyway positions.
See MIL-PRF-28876
appendix A, figure A-3.
Marking:
Part or Identifying Number (PIN):
Marked on coupling ring of plug (see
table I).
B
1
2
P
1
M28876/14
Basic PIN
Keying position number
Shell size designator
Terminus/insert style
Insert arrangement number
Backshell dash number
TABLE I.
PIN designators.
Maximum cable
Shell Designator
Insert
Terminus/
Key
outer diameter in
size
insert
arrangement
position
accordance with
number
style
backshell dash number
-1
-2
-3
11
A
1
P or S
1, 2, 3,
.250
.346
4, 5, or 6
(6.35)
(8.79)
.346
.453
13
B
1
P or S
1, 2, 3,
.285
4, 5, or 6
(7.24)
(8.79)
(11.50)
.256
.375
15
C
1 or 2
P or S
1, 2, 3,
.515
4, 5, or 6
(13.08)
(6.50)
(9.53)
23
F
1 or 2
P or S
1, 2, 3,
.866
1.000
.600
4, 5, or 6
(22.00) (25.40) (15.24)
4
