MIL-PRF-28876/14E
JJ thread
For color
Shell
Insert figure
size
5/
class 2A
band
EIA-RS359
11
B-1
Yellow
.875-20
UNEF
13
B-2
Yellow
1.000-20
UNEF
15
B-3 or B-4
Yellow
1.1875-18
UNEF
23
B-5 or B-6
Yellow
1.625-18
UNEF
FIGURE 1.
Jamnut receptacle connector with 90° backshell - Continued.
REQUIREMENTS:
Dimensions and configurations: See figure 1 herein and MIL-PRF-28876
appendix A, figure A-2, figure A-6, and figure A-7.
Weight (without termini):
Weight (ounces, (gram)), maximum
Shell size
11
10.5
ounces
(297.675 g)
13
11.5
ounces
(326.025 g)
15
14.5
ounces
(411.075 g)
23
28.0
ounces
(793.8 g)
Fiber optic cable:
Cable diameter: .315 ± .020 inch (8.00 ± 0.510 mm), or .425 ± .043 inch
(10.80 ± 1.09 mm), or .817 ± .049 inch (20.75 ± 1.24 mm).
Protective caps: Each connector shall be supplied with protective caps over
the front and rear portions of the connector.
Insert arrangement:
See appendix B of MIL-PRF-28876 for desired shell size.
Termini: Style P (pin) or S (socket). See MIL-PRF-29504/1, MIL-PRF-
29504/2, MIL-PRF-29504/12, MIL-PRF-29504/13, MIL-PRF-29504/14, and MIL-PRF-
29504/15 (For dummy terminus, see MIL-PRF-29504/3).
3
