MIL-PRF-28876/5E
Color
Shell
N
Z
Insert
band
size
dia
WW
XX
dia
figure
EIA-359
max
max
5/
11
.960
.750
.963
B-1
Yellow
.768
(24.38) (19.51) (24.46)
(19.05)
1.088
.893
.875
13
1.085
B-2
Yellow
(27.56) (22.68) (27.63)
(22.22)
15
1.257
1.080
1.275
1.062
B-3
Yellow
(31.93) (27.43) (32.38)
(26.97)
or
B-4
1.719
1.518
1.500
23
1.763
B-5
Yellow
(44.78) (38.56) (43.66)
(38.10)
or
B-6
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Dimensions apply to plated/finished part.
4. Metric equivalents (mm) are in parentheses.
5. For insert arrangement, see the indicated figure in
appendix B of MIL-PRF-28876.
Receptacle connector with straight backshell - Continued.
FIGURE 1.
REQUIREMENTS:
Dimensions and configurations: See figure 1 and MIL-PRF-28876 appendix A,
figure A-2, figure A-6, and figure A-7.
Weight (without termini):
Weight (ounces, (gram)), maximum
Shell size
11
7.0
ounces
(198.45 g)
13
8.0
ounces
(226.8 g)
15
12.0
ounces
(340.2 g)
23
24.0
ounces
(680.4 g)
Fiber optic cable:
Cable diameter: .315 ± .020 inch (8.00 ± 0.51 mm), .425 ± .043 inch (10.80
± 1.09 mm), or .817 ± .049 inch (20.75 ± 1.24 mm)
Protective caps: Each connector shall be supplied with protective caps over
the front and rear portions of the connector.
Insert arrangement:
See appendix B of MIL-PRF-28876 for desired shell size.
Termini: Style P (pin) or S (socket). See MIL-PRF-29504/1, MIL-PRF-
29504/2, MIL-PRF-29504/12, MIL-PRF-29504/13, MIL-PRF-29504/14, and MIL-PRF-
29504/15 (For dummy terminus, see MIL-PRF-29504/3).
