MIL-PRF-28876/28D
Cleaning procedures: Each shipment of connectors shall include recommended
cleaning procedures. The following wording or equivalent is recommended
"To clean, use lint free wipe dampened with alcohol and blow dry with air".
Marking:
PIN:
Marked on coupling ring of the backshell (see table I).
B
1
M28876/28
Basic PIN
Shell size designator letter
Backshell dash number
TABLE I.
PIN designators.
Cable diameter
Shell
Designator Backshell
size
range
dash
number
1L, 1
.240 - .250
(6.10 - 6.35)
2L, 2
.280 - .315
11
A
(7.11 - 8.00)
3L, 3
.305 - .346
(7.75 - 8.79)
1L, 1
.280 - .315
B
13
(7.11 - .800)
2L, 2
.305 - .346
(7.75 - 8.79)
1L, 1
.495 - .515
(12.57 - 13.08)
2L, 2
.380 - .423
(9.65 - 10.74)
15
C
3L, 3
.423 - .465
(10.75 - 11.81
4L, 4
.305 - .346
(7.75 - 8.79)
1
.768 - .866
23
(19.50 - 22.00)
F
2
.900 - 1.000
(22.86 - 25.40)
3
