MIL-PRF-28876/13E
Cleaning procedures: Each shipment of connectors shall include recommended
cleaning procedures. The following wording or equivalent is recommended
"To clean, use lint free wipe dampened with alcohol and blow dry with air".
Shell polarization: 1 through 6 keyway positions.
See MIL-PRF-28876
appendix A, figure A-3.
Marking:
Part or Identifying Number (PIN):
Marked on coupling ring of plug (see
table I).
M28876/13
B
1
2
P
1
Basic PIN
Keying position number
Shell size designator
Terminus/insert style
Insert arrangement number
Backshell dash number
TABLE I.
PIN designators.
Maximum cable
outer diameter in
Shell Designator
Key
Terminus/
Insert
accordance with
position
insert
arrangement
size
backshell dash number
style
number
-1
-2
-3
11
A
1
P or S
1, 2, 3,
.250
.346
4, 5, or 6 (6.35)
(8.79)
.453
.285
13
B
1
P or S
1, 2, 3,
.346
4, 5, or 6 (7.24)
(8.79)
(11.50)
.250
.500
.375
15
C
1 or 2
P or S
1, 2, 3,
4, 5, or 6 (12.70) (6.35)
(9.53)
1.000
.600
23
F
1 or 2
P or S
1, 2, 3,
.866
4, 5, or 6 (22.00) (25.40) (15.24)
Mating counterpart:
Plug connectors specified in MIL-PRF-28876/6 through
MIL-PRF-28876/9.
Installation and removal tools:
As specified in NAVSEA drawing 6872813.
For qualified products listing, quality conformance, and periodic
inspections, dummy termini shall be used in all unused cavities.
