MIL-PRF-28876/12E
REQUIREMENTS:
Dimensions and configurations: See figure 1 herein and MIL-PRF-28876
appendix A, figures A-2, figure A-6, and figure A-7.
Weight (without termini):
Shell size
Weight (ounces, (gram)), maximum
11
8.0
ounces
(226.8 g)
13
9.0
ounces
(255.15 g)
15
13.0
ounces
(368.55 g)
23
25.0
ounces
(708.75 g)
Fiber optic cable:
Cable diameter: .315 ± .020 inch (8.00 ± 0.51 mm), .425 ± .043 inch
(10.80 ± 1.09 mm), or .817 ± .049 inch (20.75 ± 1.24 mm).
Protective caps: Each connector shall be supplied with protective caps over
the front and rear portions of the connector.
Insert arrangement:
See appendix B of MIL-PRF-28876 for desired shell size.
Termini: Style P (pin) or S (socket). See MIL-PRF-29504/1, MIL-PRF-
29504/2, MIL-PRF-29504/12, MIL-PRF-29504/13, MIL-PRF-29504/14, and MIL-PRF-
29504/15 (For dummy terminus, see MIL-PRF-29504/3).
Cleaning procedures: Each shipment of connectors shall include recommended
cleaning procedures. The following wording or equivalent is recommended:
"To clean, use lint free wipe dampened with alcohol and blow dry with air".
Sealing gasket and o-ring: The receptacle shall include a sealing gasket or
o-ring to seal between the receptacle flange and the mounting panel.
Shell polarization: 1 through 6 keyway positions.
See MIL-PRF-28876
appendix A, figure A-3.
Marking:
Part or Identifying Number (PIN):
Marked on flange of receptacle (see
table I).
B
1
2
P
1
M28876/12
Basic PIN
Keying position
Shell size designator
Terminus/insert style
Insert arrangement
Backshell dash
3
