MIL-PRF-28876/10F
A dia max
B dia
C dia
D max
Shell
T thread
size
class 2A
Inches
mm
Inches
mm
Inches
mm
Inches
mm
11
.750-.1P-
1.028
26.11
.581
14.75
.775
19.68
1.650
41.91
.2L-D.S
.569
14.45
.755
19.17
13
.875-.1P-
1.141
28.98
.705
17.90
.900
22.86
1.800
45.72
.2L-D.S
.693
17.60
.880
22.35
15
1.062-.1P- 1.263
32.08
.877
22.27
1.025
26.03
1.950
49.53
.2L-D.S
.865
21.97
1.005
25.53
1.500-.1P- 1.703
43.26
1.299
23
32.99
1.463
37.16
2.483
63.07
.2L-D.S
1.287
32.69
1.443
36.65
NOTES:
1. Dimensions are in inches.
2. Dimensions apply to plated/finished part.
3. Metric equivalents are given for general information only.
Plug dust cover - Continued.
FIGURE 1.
REQUIREMENTS:
Dimensions and configuration:
See figure 1.
Weight:
2.5 ounces (70.875 g) maximum.
Lanyard shall be free to rotate on fastener.
Gasket shall be mechanically captive to the cover.
2
