MIL-PRF-28876/1E
Marking:
PIN:
Marked on flange of receptacle (see table I).
A
1
P
1
X
M28876/1
Basic PIN
Backshell designator
Shell size designator
Keying position number
Insert arrangement number
Terminus/insert style
TABLE I.
PIN designators.
Shell
Shell size
Insert
Terminus/
Key
Backshell
size
designator
arrangement
insert
position
designator
number
style
N, L, E, or
11
A
1
P or S
1, 2, 3,
blank
4, 5, or 6
N, L, E, or
13
B
1
P or S
1, 2, 3,
blank
4, 5, or 6
N, L, E, or
15
C
1 or 2
P or S
1, 2, 3,
blank
4, 5, or 6
N, L, E, or
23
F
1 or 2
P or S
1, 2, 3,
blank
4, 5, or 6
TABLE II.
Backshell designators.
Backshell
Receptacle
designator
configured with:
Blank
Insert retention nut
N
No insert retention nut
L
Light duty backshell
E
EMI backshell
Mating counterpart:
Plug connectors specified in MIL-PRF-28876/6 through
MIL-PRF-28876/9.
Installation and removal tools:
As specified in NAVSEA drawing 6872813.
For qualified products listing, conformance, and periodic inspections, dummy
termini shall be used in all unused cavities.
